Suntec Oil Pump AS47C1538 Type: AS47C1538

Suntec Oil Pump AS47C1538 Type: AS47C1538

The SUNTEC AS oil pump has a built in solenoid valve which controls the regulator cut-off valve giving fast cut-off and cut-on function independent of the rotational speed.

Applications

– Light oil

– One or two-pipe system

General

Mounting: Flange or hub mounting according to EN 225.

Connection threads: cylindrical according to ISO 228/1.

Inlet and return: G 1/4

Nozzle outlet: G 1/8

Pressure gauge ports: G 1/8

Vacuum gauge port: G 1/8

Shaft: ø 8 mm according to European standard EN 225.

Weight: 1.125 kg
